二叉树的垂直遍历

从左到右，从上到下遍历二叉树。二叉树的节点的值为整数。 alt text

上述二叉树的垂直遍历结果为：[6,4,2,7,1,9,10,3,8,5]

位于相同位置的不同节点的顺序应当继承自其各自的父节点。比如9和10，因为8在7之后，所以10在9之后。

| 更复杂的例子：交叉循环树上述二叉树的垂直遍历结果为： [7, 2, 5, 8, 12, 1, 4, 6, 10, 11, 3, 9, 13]

题目模版

traverse.jstraverse.ts

// This is the class for the node
// you can use this directly as it is bundled with your code
export class Node {
  constructor(val) {
    this.value = val
    this.left = null
    this.right = null
  }
}
// }
/**
 * @param {Node} root
 * @returns {number[]}
 */
export default function traverse(root) {

}

export class Node {
  value: number
  left: Node | null
  right: Node | null
  constructor(val: number) {
    this.value = val
    this.left = null
    this.right = null
  }
}

export default function traverse(root: Node | null): number[] {}

测试代码

traverse.spec.jstraverse.spec.ts

import { describe, expect, it } from 'vitest'
import traverse, { Node } from './traverse'

describe('traverse', () => {
  it('当根节点为空时应返回空数组', () => {
    expect(traverse(null)).toEqual([])
  })

  it('对于单节点树应返回单节点值', () => {
    const root = new Node(1)
    expect(traverse(root)).toEqual([1])
  })

  it('应遍历一棵左斜树', () => {
    const root = new Node(1)
    root.left = new Node(2)
    root.left.left = new Node(3)
    expect(traverse(root)).toEqual([3, 2, 1])
  })

  it('应遍历一棵右斜树', () => {
    const root = new Node(1)
    root.right = new Node(2)
    root.right.right = new Node(3)
    expect(traverse(root)).toEqual([1, 2, 3])
  })

  it('应遍历平衡树', () => {
    //      1
    //     / \
    //    2   3
    //   /   / \
    //  4   5   6
    const root = new Node(1)
    root.left = new Node(2)
    root.right = new Node(3)
    root.left.left = new Node(4)
    root.right.left = new Node(5)
    root.right.right = new Node(6)
    expect(traverse(root)).toEqual([4, 2, 1, 5, 3, 6])
  })

  it('应能处理含有重复值的树', () => {
    //      1
    //     / \
    //    2   2
    //   /     \
    //  3       3
    const root = new Node(1)
    root.left = new Node(2)
    root.right = new Node(2)
    root.left.left = new Node(3)
    root.right.right = new Node(3)
    expect(traverse(root)).toEqual([3, 2, 1, 2, 3])
  })

  it('应处理更复杂的树结构', () => {
    //        10
    //       /  \
    //      5    15
    //     / \     \
    //    3   7     18
    //         \
    //          8
    const root = new Node(10)
    root.left = new Node(5)
    root.right = new Node(15)
    root.left.left = new Node(3)
    root.left.right = new Node(7)
    root.left.right.right = new Node(8)
    root.right.right = new Node(18)
    expect(traverse(root)).toEqual([3, 5, 10, 7, 15, 8, 18])
  })

  const node = v => new Node(v)
  it('无敌连环绕', () => {
    const root = node(1)
    root.left = node(2)
    root.left.right = node(4)
    root.left.right.right = node(7)
    root.left.right.right.left = node(9)
    root.left.right.right.left.left = node(10)
    root.right = node(3)
    root.right.left = node(5)
    root.right.left.left = node(6)
    root.right.left.left.right = node(8)
    root.right.left.left.right.right = node(11)
    expect(traverse(root)).toEqual([2, 6, 10, 1, 4, 5, 8, 9, 3, 7, 11])
  })

  it('无敌叉起绕', () => {
    const root = node(1)
    root.left = node(2)
    root.left.right = node(4)
    root.left.right.left = node(5)
    root.left.right.left.left = node(7)
    root.left.right.right = node(9)
    root.left.right.right.left = node(11)
    root.left.right.right.left.left = node(12)
    root.right = node(3)
    root.right.left = node(6)
    root.right.left.left = node(8)
    root.right.left.left.right = node(10)
    root.right.left.left.right.right = node(13)
    expect(traverse(root)).toEqual([7, 2, 5, 8, 12, 1, 4, 6, 10, 11, 3, 9, 13])
  })
})

import { describe, expect, it } from 'vitest'
import traverse, { Node } from './traverse'

describe('traverse', () => {
  it('当根节点为空时应返回空数组', () => {
    expect(traverse(null)).toEqual([])
  })

  it('对于单节点树应返回单节点值', () => {
    const root = new Node(1)
    expect(traverse(root)).toEqual([1])
  })

  it('应遍历一棵左斜树', () => {
    const root = new Node(1)
    root.left = new Node(2)
    root.left.left = new Node(3)
    expect(traverse(root)).toEqual([3, 2, 1])
  })

  it('应遍历一棵右斜树', () => {
    const root = new Node(1)
    root.right = new Node(2)
    root.right.right = new Node(3)
    expect(traverse(root)).toEqual([1, 2, 3])
  })

  it('应遍历平衡树', () => {
    //      1
    //     / \
    //    2   3
    //   /   / \
    //  4   5   6
    const root = new Node(1)
    root.left = new Node(2)
    root.right = new Node(3)
    root.left.left = new Node(4)
    root.right.left = new Node(5)
    root.right.right = new Node(6)
    expect(traverse(root)).toEqual([4, 2, 1, 5, 3, 6])
  })

  it('应能处理含有重复值的树', () => {
    //      1
    //     / \
    //    2   2
    //   /     \
    //  3       3
    const root = new Node(1)
    root.left = new Node(2)
    root.right = new Node(2)
    root.left.left = new Node(3)
    root.right.right = new Node(3)
    expect(traverse(root)).toEqual([3, 2, 1, 2, 3])
  })

  it('应处理更复杂的树结构', () => {
    //        10
    //       /  \
    //      5    15
    //     / \     \
    //    3   7     18
    //         \
    //          8
    const root = new Node(10)
    root.left = new Node(5)
    root.right = new Node(15)
    root.left.left = new Node(3)
    root.left.right = new Node(7)
    root.left.right.right = new Node(8)
    root.right.right = new Node(18)
    expect(traverse(root)).toEqual([3, 5, 10, 7, 15, 8, 18])
  })

  const node = (v: number) => new Node(v)
  it('无敌连环绕', () => {
    const root = node(1)
    root.left = node(2)
    root.left.right = node(4)
    root.left.right.right = node(7)
    root.left.right.right.left = node(9)
    root.left.right.right.left.left = node(10)
    root.right = node(3)
    root.right.left = node(5)
    root.right.left.left = node(6)
    root.right.left.left.right = node(8)
    root.right.left.left.right.right = node(11)
    expect(traverse(root)).toEqual([2, 6, 10, 1, 4, 5, 8, 9, 3, 7, 11])
  })

  it('无敌叉起绕', () => {
    const root = node(1)
    root.left = node(2)
    root.left.right = node(4)
    root.left.right.left = node(5)
    root.left.right.left.left = node(7)
    root.left.right.right = node(9)
    root.left.right.right.left = node(11)
    root.left.right.right.left.left = node(12)
    root.right = node(3)
    root.right.left = node(6)
    root.right.left.left = node(8)
    root.right.left.left.right = node(10)
    root.right.left.left.right.right = node(13)
    expect(traverse(root)).toEqual([7, 2, 5, 8, 12, 1, 4, 6, 10, 11, 3, 9, 13])
  })
})

答案

类型	路径
JS 版本	problems/Day 09/answer.js
TS 版本	problems/Day 09/ts/answer.ts
Review	09.md
